sPINner (Horizontal Movement)
* The horizontal movement can grind every corner uniformly.
* The effective grinding area is 600 × 900 mm.
* Best for long parts, such as CNC-milled plate, panels, or rods
Aluminum Panel Grinding Case
Features
*Grinds for High Precision
Best for High-Precision Parts such as gears, special screws.
Best for fragile, thin, long parts
*Grinds Every Corner
The pins reach every corner. Best for irregular parts.
Effect
*Deburring & Slightly Rounding Sharp Edges
*Polishing, Removing Machining Marks and Oxide Layers
Video
Specifications
| MODEL | DIMENSIONS （LxWxH） | CONTAINER SIZE | POWER | WEIGHT |
|---|---|---|---|---|
| HD-7165 | 1360x1070x1365 mm | 900x600mm | one Φ AC220 (50/60HZ) |
281KG |
| MODEL | MAX GRINDING CAPACITY（KG） | ACCESSORIES | |
|---|---|---|---|
| HD-7165 | Copper, Stainless steel, (Non-Magnetic material) |
12 KG | 1. Stainless pins 15 KG 2. Plastic container 1 set 3. Separating container 1 set 4. Magnetic Sleeve 2 set 5. Grinding liquid (15,000c.c.) 6. Operation manual |
| Aluminum, Zinc, Iron, Steel, Stainless steel (Magnetic material) |
6 KG | ||
Operations
* Main Control Panel
1.(FINISHED ALARM): It sounds, and indicator lightens as soon as the procession has completed.
2.Frequency display and error message display: Show the preset running frequency or the error message.
3.SPEED ADJUST: The setting range is between 10 to 60Hz.
4.Frequency display (LED).
5.Grinding program 1: 5a is the timer, and 5b is the rotation direction control.
6.Grinding program 2: 6a is the timer, and 6b is the rotation direction control.
7.Power source.
8.Start: Push the button to start the operation.
9.Stop: Push the button to stop the operation.
* Horizontal Movement Control Panel
1. Horizontal movement speed adjustment: Adjust the speed of the horizontal movement of the magnetic field.
2. Horizontal movement switch: Turn on/off the horizontal movement.
3. Horizontal movement direction indicator.
